72 FO Fiber Optic Closure horizontal tyep

GJS09-JTH-TX12/72B

72Cores Mechanical Sealing Fiber Optic Enclosure Caja Fibra Optica

FTTH Fiber Optic Splice Closure GJS09-JTH-TX12/72B is used as a termination point for the feeder cable to connect with feeder cable in the FTTx communication network system. The fiber splicing, splitting, and distribution can be done in this box, and meanwhile, it provides solid protection and management for the FTTx network building.FTTH Drop Cable Type Fiber Optic Splice Closure features with ruggedness, which is tested under harsh conditions and stands up to even the most severe conditions of moisture, vibration, and extreme temperatures. Humanized design helps the user get a better experience and safer operating environments.

Specification:

Impact Test: IK10

Pull Force:100N

Environmental requirement

Working temperature: -40℃~+85℃

Relative humidity: ≤85% (+30℃)

Atmospheric pressure: 70KPa~106Kpa

Thunder-proof technical datasheet

The insulation resistance between the grounding device and the metal parts of the box is no less than 2MΩ/500V (DC); IR≥2MΩ/500V.

The voltage resistance between the grounding device, and the box and its metal parts is no less than 3000V (DC)/min, no puncture, no flashover; U≥3000V
